Show differences only
|
Systems
|
TopLine XL
|
TopLine L
|
SlideLine M, overlay
|
|---|---|---|---|
|
|
|
|
Description |
Top running sliding door system for large cabinets with 2, 3 or 4 doors | Top running sliding door system for large cabinets with 2 or 3 doors | Bottom running sliding door system with one runner |
Number of tracks |
2 | 2 | 1 |
Door action |
Horizontal | Horizontal | Horizontal |
Door position |
Overlay | Overlay | Overlay |
Door weight |
100 kg max. | 50 kg max. | 30 kg max. |
Door material |
Wood | Wood | Wood / glass |
Door width |
600 - 2000 mm | 550 - 1500 mm | 300 - 1800 mm |
Door height |
3000 mm max. | 2600 mm max. | 2000 mm max. |
Silent System |
Soft closing, soft opening |
Soft closing, soft opening, soft colliding |
Soft closing, soft opening, soft colliding |
Locking system |
Mechanical | Mechanical | Mechanical |
Description
Silent System
